• AGW-11180401

Genwec

Urinal divider AISI 304 brushed

Urinal divider AISI 304 brushed

1 in stock
CHF 105.00
CHF 105.00
plus VAT | Shipping calculated at checkout.

Pay securely with

Twint PayPal Visa Maestro American Express Apple Pay Generic

AGW-11180401

Downloads

Datasheet

Product features

material
  • stainless steel

Color
  • Stainless steel, matte/satin finish

Description

90° Angled Grab Bar with three mounting points
Made of high-quality stainless steel AISI 304
Tube diameter of 32 mm for optimal grip
Mounting flanges made of galvanized steel with corrosion protection
Includes cover plates for concealed screw mounting
Brushed surface for an attractive appearance
Vandalism-proof design for heavy-duty use
Heavy-duty quality for maximum safety

Technical Details:
- Type: 90° Angled Grab Bar
- Tube Material: Stainless steel AISI 304
- Tube Diameter: 32 mm
- Tube Wall Thickness: 1.5 mm
- Surface: Brushed
- Load Capacity: Max. 120 kg

Dimensions:
- Leg Length 1: 700 mm
- Leg Length 2: 700 mm
- Flange Diameter: 75 mm
- Overall Dimensions: 700 x 700 mm

The Genwec AGW-11180401is a 2-wall grab bar made of AISI 304 stainless steel, matt brushed, Ø 32 mm, 700×700 mm – for accessible toilets according to DIN 18040, with mounting on two wall surfaces.

Advantages

  • 2-wall mounting 700×700 mm – optimal support when standing up and sitting down.
  • AISI 304 stainless steel, matt brushed – robust, corrosion-resistant, easy to clean.
  • Concealed wall mounting on both legs – no visible screws.
  • Mounting material included.

Limitations

  • Only available in one size (700×700 mm).
  • Only for solid walls – hollow walls require preparation.
