Stainless steel shower panel with infrared electronics and thermostatic mixer, 24V

Product type: Stainless steel shower panel with infrared electronics and thermostatic mixer
Material: Stainless steel AISI 304 (V2A)
Surface: Brushed
Features: Hygienic flush, adjustable water jet angle, scald protection, automatic water flow,
adjustable run-on time, automatic water stop after 5 minutes, parameter setting via remote control
SLD 03 (optional) possible

Technical specifications – ASA-SLSN 02ET (mains powered):
- Power supply: 24 V DC (via external power supply unit)
- Operating pressure: 0.1 – 0.6 MPa (1 – 6 bar)
- Flow rate: 9 l/min
- Water connection: External thread G 1/2“

Dimensions (for both models):
- Height: 1100 mm
- Width: 160 mm
- Depth (housing): 60 mm
- Depth (incl. shower head): approx. 110 mm
- Recommended mounting height (bottom edge): 1000 mm above floor

The Sanela stainless steel shower panels SLSN 02ETB and SLSN 02ET are high-quality, wall-mounted shower systems
made of robust stainless steel AISI 304, ideal for public and commercial sanitary areas.
Both models feature integrated infrared electronics for touch-free and hygienic operation
as well as a thermostatic mixer for precise temperature control of cold and hot water.
Integrated scald protection ensures maximum safety. Water flow starts automatically upon
approach and stops after an adjustable run-on time or after 5 minutes of continuous operation.
Model SLSN 02ETB is powered by 6 V batteries, while model SLSN 02ET uses a 24 V DC
mains power supply. Both offer a flow rate of 9 l/min.
The durable brushed surface is easy to clean and flexible parameter setting is possible via the optional
remote control SLD 03 (optional) or with the Sanela App.

Scope of delivery: Shower panel with electronics, solenoid valve (1 pc), thermostatic mixer, connection hose, angle valve with filter and backflow preventer (2 pcs)
