• ASA-SLSN 02ETB

SANELA | ASA-SLSN 02ETB

Stainless steel shower panel with infrared electronics and thermostatic mixer, 6V

Stainless steel shower panel with infrared electronics and thermostatic mixer, 6V

Awaiting stock, shipping soon
CHF 1,357.00
CHF 1,357.00
plus VAT | Shipping calculated at checkout.

Delivery in approx. 2–3 weeks.

Special B2B prices?

  • American Express
  • Apple Pay
  • Google Pay
  • Klarna
  • Mastercard
  • Shop Pay
  • Twint
  • Union Pay
  • Visa

ASA-SLSN 02ETB

Description

Product Type: Stainless Steel Shower Panel with Infrared Electronics and Thermostatic Mixing Valve
Material: Stainless steel AISI 304 (V2A)
Surface: Brushed
Features: Hygienic flush, adjustable spray angle, anti-scald protection, automatic water flow,
adjustable run-on time, automatic water stop after 5 minutes, parameter setting via remote control
SLD 03 (optional) possible

Technical Specifications - ASA-SLSN 02ETB (Battery operated):
- Power supply: 6 V (4 pcs. AA Alkaline batteries 1.5 V, 2700 mAh)
- Battery life: approx. 2 years (with 100 uses per day)
- Operating pressure: 0.1 – 0.6 MPa (1 – 6 bar)
- Flow rate: 9 l/min
- Water connection: External thread G 1/2“

Dimensions (for both models):
- Height: 1100 mm
- Width: 160 mm
- Depth (housing): 60 mm
- Depth (incl. shower head): approx. 110 mm
- Recommended mounting height (bottom edge): 1000 mm above floor

The Sanela stainless steel shower panels SLSN 02ETB and SLSN 02ET are high-quality, wall-mounted shower systems
made of robust stainless steel AISI 304, ideal for public and commercial sanitary areas.
Both models feature integrated infrared electronics for contactless and hygienic operation
and a thermostatic mixing valve for precise temperature control of cold and hot water.
Integrated anti-scald protection ensures maximum safety. Water flow starts automatically upon
approach and stops after an adjustable run-on time or after 5 minutes of continuous operation.
Model SLSN 02ETB is powered by 6 V batteries, while model SLSN 02ET uses a 24 V DC
mains power supply. Both offer a flow rate of 9 l/min.
The durable brushed surface is easy to clean, and flexible parameter setting is possible via the optional
remote control SLD 03 (optional) or with the Sanela App.

Scope of delivery: Shower panel with electronics, solenoid valve (1 pc.), thermostatic mixer, connection hose, angle valve with filter and backflow preventer (2 pcs.)

The SANELA SLSN 02ETBis a stainless steel shower panel with infrared electronics and integrated thermostatic mixer, battery-powered (6V) – for public sanitary facilities with hot and cold water connection without mains power supply.

Advantages

  • Infrared sensor – contactless activation, maximum hygiene.
  • Integrated thermostatic mixer – pre-adjustable mixed water temperature.
  • 6V battery operation – no mains voltage required, easy installation.
  • Self-closing – flow time adjustable; water flow stops when leaving the detection range.
  • Flow rate 6 l/min – stable even with pressure fluctuations.
  • Stainless steel AISI 304, satin finish – hygienic, corrosion-resistant, easy to clean.
  • Concealed, reinforced wall mounting – vandal-resistant.
  • Hygiene flush – automatically flushes after a defined idle period, reduces legionella risk.
  • Battery accessible from below – without dismounting the panel.
  • Surface mounting – no concealed installation required.

Limitations

  • Hot and cold water connection required on site.
  • Battery replacement required (6V).
