Stainless steel RFID token shower panel with mixer for hot and cold water

- Vandal-proof design made of AISI-304 stainless steel, with a matte brushed finish.
- Wall-mounted shower panel with integrated RFID reader for SANELA tokens (SLZA 51).
- Activation by holding the charged RFID token in front of the reader (confirmed by a flashing red LED).
- Water start via piezo button with a countdown display using 10 red LEDs.
- Start-stop function allows the user to interrupt the water flow.
- Warning function: Brief water interruption when 30% of the paid remaining time is reached.
- Option to restart the sequence by holding the token in front of the reader again during showering.
- Integrated hygienic flush to prevent stagnant water.
- Parameter adjustment is done via a special setting token.

Technical details:
Operating voltage: 24 V DC
Power consumption: 7 W
Recommended water pressure: 0.1 - 0.6 MPa
Flow rate: 9 l/min. (inf. Data)
Water inlet: G 1/2“ male thread

Scope of delivery: Stainless steel shower panel with electronics and RFID reader, shower head with adjustable spray angle,
solenoid valve (1 pc.), mixer, connection hoses, angle valve with filter and backflow preventer (2 pcs.).
