Accessible toilet dimensions: What's important for safe and comfortable use
Accessible toilets give people with physical disabilities more independence and safety in their daily lives. But what exactly makes an accessible toilet, and what should be considered during planning, construction, or retrofitting? Factors such as size and depth, seat surface and height, backrest, folding support handles, and toilet paper holders play an important role. In this article, we provide an overview of the correct dimensions – from maneuvering areas to grab bar positions and seat height – and show what planners and builders should pay particular attention to. Because proper planning means free access for everyone. And Armatron makes this possible!
Accessible Toilets: Dimensions and Requirements for Greater Inclusion
Accessible toilets are central components of modern, inclusive sanitary facilities – both in public areas and private homes. Correct dimensions are crucial to enable people with physical disabilities to use them safely and independently. That’s why suitable solutions are important – especially regarding functionality, user-friendliness, freedom of movement, and comfort. Armatron offers exactly that: Our accessible toilet models meet the highest quality standards and can be individually integrated into existing structural conditions. Furthermore, we always ensure compliance with mandatory norms and standards for the prescribed maneuvering areas, gripping heights, and equipment details applicable in Switzerland. This includes, among others, SIA 500 for barrier-free construction. This way, we not only create legal certainty but also enable a long-term, future-proof outfitting of your sanitary objects – from new construction to retrofitting.
What Regulations Apply and What You Need to Consider
For a toilet to be considered truly accessible, specific dimensional requirements must be met. The Swiss standard SIA 500 prescribes a projection of at least 65 cm from the back wall for the toilet bowl – so that people with disabilities or wheelchair users have enough space to use the toilet without restriction. The room itself must measure at least 1.65 x 1.80 m, with correspondingly more space needed if the door opens inwards. The seat height (top edge of the toilet seat) is 46 cm, which facilitates a safe transfer from a wheelchair to the toilet. Toilet paper holders must be mounted within the lateral gripping zone next to the toilet, ideally in conjunction with a folding support handle, which, like the toilet flush and flush release, must be ergonomically planned and implemented. This ensures safe and independent access. The correct side is also crucial: the holder must be installed on the side opposite the transfer. The door must open outwards and must not be equipped with a door closer, so that maneuvering with a rollator or wheelchair is possible without restriction. Furthermore, it is sensible to also consider access to the toilet, for example, through wider doors and threshold-free transitions.
Our experts at Armatron will be happy to advise you on the individual implementation of your renovations or new constructions, provide tips, and offer you tailor-made products and solutions that are standard-compliant, high-quality, and at the same time aesthetically pleasing. If you need information, please feel free to contact us directly.
The most important dimensions summarized briefly:
-
- Seat height (top edge of toilet seat): 46 cm
- Toilet bowl projection from back wall: min. 65 cm
- Total room size: min. 1.65 × 1.80 m (with door opening outwards)
- Horizontal grab bar: height 70–75 cm from floor
- Folding support handle: operable with one hand, min. 65 cm distance next to the toilet
- Door width: min. 0.80 m, opening outwards, without door closer
- Mirror: permanently mounted, tilting mirror not permitted
Planning Principles: SIA 500 Standard
This standard establishes the central requirements for barrier-free construction in Switzerland, thus also providing information on the correct dimensions for accessible toilets. Furthermore, it applies not only to public buildings but also serves as an essential basis in private residential construction, especially for future-oriented usage concepts. Particular attention should be paid here to the maneuvering areas around the toilet, which are intended to ensure free accessibility, reachability of all components, and the correct positioning of aids, such as backrests. The goal is to enable people with mobility impairments to use the toilet without assistance. Therefore, anyone planning or needing to plan barrier-free construction should first check whether the structural conditions, such as appropriate room size, door widths, and installation heights, meet the respective requirements.
Good to know: In Germany, the DIN 18040-1 standard applies, which is not officially used in Switzerland, although it often serves as a guide in professional circles. However, Swiss planners and architects must fundamentally adhere to SIA 500, as it is binding for barrier-free construction and building projects with building permits. The German standard deviates from Swiss requirements in some regulations, usually prescribing slightly smaller dimensions. Furthermore, in Switzerland, there is a stronger focus on lateral transfer areas and the use of sanitary rooms in wheelchairs.
More Than Standard: Individual Solutions for Individual Requirements
Whether it's a renovation, conversion, retrofitting, or a complete new build – whether in existing buildings, hotels, public facilities, for residents of a care facility, or in private homes – every structural situation brings its own unique challenges. That's why, when needed, it's so crucial to never rely on off-the-shelf products and sanitary solutions, but rather on individually tailored concepts. If you want to play it safe with accessible toilets and toilet facilities, opt for toilet systems with versatile equipment options and full accessibility. Armatron is exactly the right partner for you, as we offer the integration of different heights, depths, handles, and flushing mechanisms – always exactly as the environment and your requirements demand. Because our accessible sanitary solutions are born from a clear understanding of our customers' needs. This is how we develop products that truly improve the daily lives of people with limited mobility.
Why Armatron?
Our accessible toilets not only offer safety and independence for users. They also impress with their first-class construction and manufacturing, high-quality materials, and attractive design language. Furthermore, we offer various designs: stainless steel and easy-to-clean surfaces ensure particular durability and simple maintenance. Models like the PMR toilet SLWN 11 with extended projection or the wall-hung toilet 700 S have been specially developed for accessible requirements and meet both functional and aesthetic demands at the highest level. Armatron stands for a high-quality promise – from the initial planning to the selection of the appropriate equipment. Our toilet solutions are not only tailored to current needs but can also be flexibly integrated into future sanitary concepts. Solutions that last for years – technically always up-to-date, reliable in application and function, and always stylistically convincing. Trust in our experience, our know-how, and our passion – for an accessible bathroom or toilet that gives people the space they truly need.
