ALAVO - Our complete solution for the upmarket washroom

Banner-ALAVO

ALAVO in focus:

You have no space to waste and like tidy and user-friendly washrooms? At the same time, do you attach great importance to an environmentally friendly use of resources? Developed in close cooperation with leading architects, designers and customers, ALAVO offers a unique overall concept - space-saving, elegant and environmentally friendly!



The advantages of ALAVO

ICON_Design_80

MODERN DESIGN

ALAVO convinces through a tidy and modern design - comprehensible LED symbols on the mirror show the user the position of the concealed applications.

ICON_mudular_80

MODULAR

ALAVO has a modular structure. You determine the scope and equipment of ALAVO - For example, you would rather have a paper towel dispenser than a hand dryer - no problem. ALAVO is built for your setup.

ICON_contactless

HYGIENIC

Maximum hygiene thanks to modern technology - all fittings work completely contact-free.

ICON_Light_80

STYLISH

Durable and energy-saving LED tapes provide for a pleasant atmosphere - On request we equip ALAVO also with colour LEDs. For example, immerse your washroom in the corporate colour of your company.

ICON_cost-saving_80

ENVIRONMENTALLY FRIENDLY AND RESOURCE-SAVING

ALAVO is easy to install, uncomplicated to clean and reduces the need for water, soap and energy - which not only saves valuable resourcesthat also saves Time and money.

ALAVO not only offers a convincing design and an excellent user experience - as an overall concept, ALAVO reduces the use of resources. You save water, energy, space, time and money!



WATER
WATER
ALAVO is easy to install and also to service. All water installations are fully accessible at all times by folding up the mirror from the front.

Touchless water taps with infrared sensor offer maximum hygiene, are easy to operate and allow water savings of up to 65%.

SEIFE
SEIFE
The automatic foam soap dispenser with infrared sensor is triggered by the approach of the hand and dispenses a predefined amount of foam soap.

A soap tank with a capacity of 7 litres provides foam soap for up to 17,500 operations.

An LED warning light integrated in the mirror indicates to the cleaning staff that the soap tank will soon be empty and refilling will be necessary.

HAND DRYER
HAND DRYER
Hand dryers with strong air flow dry hands in approx. 13 seconds. Compared to conventional hand dryers, power consumption can be reduced by up to 70%.

The hand dryer can simply be plugged into the power rail integrated into the system. This allows for easy removal, whether for replacement or subsequent conversion to paper towel dispensers.

What else ALAVO offers:

LIGHTING
  • Long-lasting and energy-efficient LED strips are not only environmentally friendly - they also function reliably in extremely warm or cold temperatures.
  • The high-quality LED lighting provides uniform light distribution and can be quickly switched to a desired colour.
MODULAR STRUCTURE
  • Whether for a single wash station (Supaloo version) or for larger washrooms with several wash stations - the modular design of ALAVO allows a solution for almost any setup.
  • Up to 8 wash places can be supplied from a single water and electrical access.
ELECTRONICS & SAFETY
  • Each unit is supplied by a single power access and is protected by a residual current circuit breaker.
  • All transformers, circuit boards and LED controls are centrally located in one place. The other connections work with a simple 'plug and play' connection system.
MAINTENANCE
Maintenance work is kept to a minimum and includes the annual adjustment of the mixing valves (if installed).
CONSUMABLES
  • Paper towels can be refilled quickly and easily
  • You are not tied to a specific manufacturer or supplier. ALAVO therefore gives you maximum flexibility.
INTEGRATION
  • The system can alternatively cover fitting distances of 600, 750 and 900mm.
  • The hinged mirrors are 1000mm high to ensure safe and easy access for cleaning and maintenance personnel. For the Supaloo version, the mirror is typically 800mm high to allow access in confined spaces.
  • ALAVO is modular and offers a wide range of possibilities - also for your washroom. Simply send your enquiry to info@www.armatron.ch.
INSTALLATION
The system consists of modules pre-assembled at the factory. Installation on site is done in a few simple steps:

  1. Fix the mounting rail to the wall
  2. Place the first module on the mounting rail and fix it to the wall.
  3. Hang and fix all remaining modules one after the other
  4. Install mirror flaps
  5. Connect water and electronic connections
